Salt water chlorinator BSV Smart Basic 25 g/h + pH regulator Seko Dinamik + Zodiac 20 XA
ref: 01EQCSPHLF21
The pack includes:
- Salt chlorinator BSV SMart Basic 15
production: 15 g/h - PH regulator Seko Dinamik
- Cleaner Zodiac 20 XA
cleaning of the bottom, walls and waterline
Free shipping
Technical characteristics
Salt water chlorinator BSV Smart Basic 25
what is a salt chlorinator for?
Quite simply, the function of salt chlorinators is to automatically and effectively disinfect the pool water, using a process called "salt electrolysis".
Salt electrolysis is a simple principle: the pool water is slightly salty. By electrolysis, through the cell, the salt is transformed into gaseous chlorine, a powerful disinfectant that dissolves instantly in the water.
This results in the destruction of the micro-organisms in the cell and provides the pool with the correct level of free chlorine.
The idea of installing a salt chlorinator in the pool is to save us worries and to gain in comfort.
Benefits of salt chlorination
- forget about chlorine! We only add salt to the pool water.
- Concentration similar to that of a teardrop.
- We avoid the use and handling of chemical products.
- Elimination of skin and eye irritations.
- Elimination of chlorine smell.
- No damage to hair or bathing clothes.
- Generates a cleaner environment in the pool.
- Reduction of pool maintenance.
- Compatibility with any type of installation.
- Better balance of water parameters in the pool (with the help of pH and redox regulators).
Features of the salt water chlorinator BSV Smart Basic 25
Cell
Self-cleaning cell with an output of 15 g/h.
IP65 protection
Sealing protection against water, corrosive gases and vapours.
Digital display
Angled housing designed for better viewing.
Automatic shutdown
For lack of flow, gas accumulation, overload, short circuit and overtemperature.
- Lower power consumption.
- Lower working temperature.
- Greater performance in chlorination as it works with the latest generation of switched sources.
- Internal microprocessor control to determine the hours of operation.
- It works with a very low voltage, less than 7.5 V.
- No electrical risk for bathers.
Sustainability and savings
- Allows the pool water to be conserved for a longer period of time.
- The salt remains in the process and is transformed. This saves on the purchase of chemical products.
- Environmentally friendly system.
Guarantee
The BSV Smart Basic salt water chlorinator comes with a 3 year warranty.
If you need more information about this equipment or about any other salt chlorinator BSV, do not hesitate to contact us.
 | | | |
| Smart Basic 15 | Smart Basic 25 | Smart Basic 35 | |
| Supply voltage | 230 Vac - 50 Hz / 60 Hz | 230 Vac - 50 Hz / 60 Hz | 230 Vac - 50 Hz / 60 Hz |
| Maximum cell current | 15 A | 25 A | 35 A |
| Maximum power | 112.5 W | 187.5 W | 263 W |
| Maximum cell voltage | 7.5 Vdc | 7.5 Vdc | 7.5 Vdc |
| Language selection | No | No | No |
| Manual chlorine regulation | Yes | Yes | Yes |
| Automatic chlorine regulation | No | No | No |
| Redox reading indication | No | No | No |
| PH reading indication | No | No | No |
| Lack of salt indication | Yes | Yes | Yes |
| Excess salt indication | Yes | Yes | Yes |
| Water temperature indication | No | No | No |
| Self-cleaning | Yes | Yes | Yes |
| Salt level indicator | No | No | No |
| Cell life status indicator | No | No | No |
Peristaltic pH regulating pump BSV QS-pH
Characteristics:
- Flow rate of 1.5 l/h at 1.5 bar.
- PH measuring range: 5 to 9 (sensitivity of 0.1).
- Power supply: 90/265 VAC.
- BNC connector for pH electrode.
- Dosing method: ON-OFF (adjustable set point).
- PH 1-point calibration method.
- Includes:
- 6 metre pH probe
- pH7 calibration solution
- 2 collars
- calibration plug
Peristaltic pump warranty: 3 years. Incorrect fitting of the pH probe will invalidate the warranty. The probe is a consumable not covered by the warranty, so it will be up to the manufacturer to determine in each case whether or not the warranty is applicable.
Robot cleaner Zodiac 20 XA
Electric pool cleaners are increasingly winning over pool owners thanks to the daily peace of mind they provide: performance, autonomy, good filtration, ease of use...
They are more accessible and the Zodiac team has noticed that users are becoming more and more demanding in terms of cleaning. They say they are willing to invest a little more money to obtain perfect cleaning.
The R&D teams at Zodiac focused on achieving the ideal conditions for this expected performance.
Forget about cleaning and enjoy your pool with all the experience and guarantee that the Zodiac brand offers in its products.
In addition, with your purchase at Quimipool you will enjoy the Priority Pass Technical Service.
Cyclonic suction
Its patented cyclonic suction system provides more powerful and long-lasting suction. The helical-shaped brushes and progressive dual-level filtration enable more effective suction of debris.
During the cleaning cycle, a conventional electric pool cleaner tends to become clogged, thus losing its suction power.
To solve this problem, Zodiac engineers have developed and patented cyclonic suction technology, a high-performance system that prevents filter clogging and maintains total efficiency:
A vortex keeps the vacuumed debris in suspension in a permanent cyclonic motion. The power of the vortex prevents fine debris from adhering to the filter walls and prevents it from accumulating on the filter walls.
The ZODIAC 20 XA is equipped with 3 motors. Two movement motors and one suction motor, which greatly improves the performance of the equipment to ensure effective pool cleaning.
Spiral-shaped brushes
These brushes allow a more efficient cleaning of debris, picking up even the finest debris.
Simple filtration
Filtration of 100μ, which allows the suction of small and large particles.
Transparent lid
Helps to clearly visualise the amount of waste collected in the filter.
Versatility
The equipment adapts easily to pools of different shapes and with any liner. Ideal for pools up to 10 x 5 metres.
Type of cleaning
The ZODIAC 20 XA has the ability to efficiently clean the bottom, walls and waterline.
Cleaning cycles
Two cleaning modes:
- Bottom only
- Bottom, walls and waterline
Agile movement
Thanks to its unique design and integrated smart sensors, it offers limitless agility for excellent pool cleaning coverage.
Large suction capacity
The ZODIAC 20 XA has a wide suction nozzle of 23 cm, which allows a higher suction capacity.
Top access to the filter
The filter is accessible from the top, which simplifies its use and handling. The filter has a capacity of 4 litres.
Guarantee
The ZODIAC 20 XA pool cleaner comes with a 3 year guarantee.
* The correct operation of the equipment cannot be guaranteed both on the bottom and on the rise of the walls as long as the pH level is not correct, there is slime or algae or the filters are clogged by excess dust, and the pool has not been previously completely cleaned. No pool cleaner will clean steps and benches properly.
* The cleaning of right angles and corners cannot be 100% guaranteed due to the complexity of access to these areas. In liner pools, 100% cleaning cannot be guaranteed in the overlaps of the liner itself.
If you need more information about this equipment or any other pool cleaner Zodiac, please do not hesitate to contact us.
Supplied with:
Control unit
100μ single rectangular filter
Base for control unit
 |  |  | |
| 20 XA | 30 XA iQ | 40 XA iQ | |
| ZODIAC PRIORITY PASS SERVICE | YES | YES | YES |
| BACKGROUND | Yes | Yes | Yes |
| WALLS | Yes | Yes | Yes |
| WATERLINE | Yes | Yes | Yes |
| SURFACES | Gresite, concrete, liner, polyester | Gresite, concrete, liner, polyester | Gresite, concrete, liner, polyester |
| PATENTED CYCLONIC SUCTION | Yes | Yes | Yes |
| BRUSHES | Helical-shaped front brushes | Front and rear helicoidal brushes | Front and rear helical |
| TRACTION SYSTEM | Tracks: 2 engines | Tracks: 2 engines | Tracks: 2 engines |
| FILTER ACCESS | Upper | Superior | Superior |
| FILTRATION | Single: 100 μ | Double level: 150/60 μ | Double level: 150/60 μ |
| CLEANING CYCLES | 2 | 2 | 2 |
| BOTTOM ONLY CYCLE | Yes | Yes | Yes |
| BOTTOM/WALLS/FLOATLINE CYCLE | Yes | Yes | Yes |
| CABLE LENGTH | 15 metres | 18 metres | 18 metres |
| IAqualink APP | No | Yes | Yes |
| WATER OUTLET LIFT SYSTEM | No | No | Yes |
| TRANSPARENT LID | Yes | Yes | Yes |
| ILLUMINATED FILTER | No | Yes | Yes |
| CYCLE START, STOP AND MONITORING | No | Yes | Yes |
| REMOTE CONTROL | No | No | Yes |
| MANUAL CLEANING TIME ADJUSTMENT | No | No | Yes |
| WARRANTY | 3 years | 3 years | 3 years |
Data Sheet
- gr/hour CL
- 25-29 g/hour
- With pH control
- Yes
- Type of cleaner
- Battery
